| SPECIFICATIONS | |
|---|---|
| Receiving interval | Approx. 0.5s intervals |
| Auto power function | ・When the APO mark is lighting, the power is automatically turned off approx.30min after the last switch operation ・This function is disabled during communication connection (when the APO mark is off) |
| Data hold function | Pressed switch for holding value |
| Over range indication | Same as other connected measuring instruments |
| Data hold indication | “DH” mark on LCD with data hold value |
| Max(Peak) hold function | Only HCL-36UX and ALCL-80X can be used “MAX” mark on LCD with data hold value |
| Record function | ・Data can be retained even when power off ・Recoreded data can be saved onto the 4 data spaces every time pressing the Storage switch |
| Harmonics current display function | Only ALCL-80X can be used The RMS→fundamental →third harmonic measurement value is displayed |
| Low battery indication | “Battery” icon on LCD |
| Operating Temperature | Same as other connected measuring instruments |
| Storage Temperature | Same as other connected measuring instruments |
| Power supply | AAA alkali Battery x 3 |
| Power consumption | ・Communication standby: Approx.12mA ・Communication connection: Approx.6mA |
| Size | 76(W)x97(H)x50.4(D)mm |
| Weight | Approx. 180g (with batteries inside) |
| Accessories | Instruction manual:1 Batteries:3 |
